Tektronix A622 Current Probe, AC/DC, 50 mA, 71 A, 100 kHz, 600 V, CAT3, 11.8mm, 100 A, A600 Series-Tektronix Company

Tektronix A622 Current Probe, AC/DC, 50 mA, 71 A, 100 kHz, 600 V, CAT3, 11.8mm, 100 A, A600 Series

$1,130

Model :

A622

Tektronix A622 AC Current Oscilloscope Probe

Features and Specifications

AC/DC - 100 kHz
50 mA to 100 A peak
For DMMs and oscilloscopes
BNC1 Termination
11.8 mm Max conductor diameter
600 V (CAT III) Max bare-wire voltage

This "long nose" style clamp-on probe uses a Hall Effect current sensor to provide a voltage output to oscilloscopes. It has a BNC connector and can be used with a shrouded banana plug adapter1 so it can also be used on digital multimeters, TekMeter, and oscilloscopes. The A622 can measure AC/DC currents from 50 mA to 100 A peak over a frequency range of DC to 100 kHz. It provides 10 mV or 100 mV output for each Amp measured.

*Note: For instruments with banana jack inputs, Tektronix part number 012-1450-00 Female BNC to banana lead adapter is required.

Brand: Tektronix

Bandwidth: 100 kHz

Maximum Current: 71 A

Series: A600 Series

Input Coupling: AC/DC

Safety Rating: CAT3

Max Input Voltage: 600 V

Maximum Wire Size: 11.8 mm

Minimum Current: 50 mA

Peak Current: 100 A
