Tektronix A621 Current Probe, AC, 10 mA, 1000 A, 50 kHz, 600 V, CAT3, 54mm, 2000 A, A600 Series-Tektronix Company

Tektronix A621 Current Probe, AC, 10 mA, 1000 A, 50 kHz, 600 V, CAT3, 54mm, 2000 A, A600 Series

$1,130

Model :

A621

Tektronix A621 AC Current Oscilloscope Probe

Features and Specifications

AC - 5 Hz to 50 kHz
100 mA to 2000 A peak
For DMMs and oscilloscopes
Clamp on
BNC1 Termination
54 mm (2.13 in.) Max conductor diameter
600 V (CAT III) Max bare-wire voltage

This industrial-style clamp-on probe has a BNC connector and can be used with a shrouded banana plug adapter 1 so it can be used on digital multimeters, TekMeter, and oscilloscopes. The A621 can measure AC currents from 100 mA to 2000 A peak over a frequency range of 5 Hz to 50 kHz. It provides a 1 mV, 10 mV, or 100 mV output for each Amp measured.

*Note: For instruments with banana jack inputs, Tektronix part number 012-1450-00 Female BNC to banana lead adapter is required.

Brand: Tektronix

Bandwidth: 50 kHz

Maximum Current: 1000 A

Series: A600 Series

Input Coupling: AC

Safety Rating: CAT3

Max Input Voltage: 600 V

Maximum Wire Size: 54 mm

Minimum Current: 10 mA

Peak Current: 2000 A
