ITECH IT6302 DC Power Supply, Triple Output, 2x 30 V/ 3 A / 90 W, 1 x 5 V / 3 A / 15 W, IT6300 Serie
$585
Model :
- IT6302
IT6302 Triple Channels DC Power Supply
IT6300 series is a high-performance programmable triple channel DC power supply, each output voltage and current can be set from 0 to its maximum rating. The units support series connection, parallel connection and synchronous functions of channel, which offer multi-purpose test solutions for users. Its high resolution 1mV / 1mA and remote sense function enable more accurate testing while built-in standard USB / RS232 communication interfaces enhance communication speed. In addition, customers can adjust the digital step value using the on-screen cursor for futher operations.
Specifications:
- Independent, fully programmable and electrically isolated outputs
- Display & adjust voltage and current settings for all 3 channels
- Flexible output configuration: connect CH1 or CH2 channels in parallel
- Excellent stability and regulation
- LVP (low voltage protection) and OTP (over temperature protection)
- Output on/off control
- 27 memory locations for instrument state
- Storage & recall
- Closed case calibration
Brand: ITECH
Includes: Power cord, Factory calibration certificate
Number of Outputs: Triple Output
Output Voltage: 5V, 30V x 2
Power Rating: 15 W
Series: IT6300 Series
Interface: None
Mounting Type: Bench Top
Output Current: 3A
Input Voltage: 110/220 VAC
Special Features: Isolated Outputs
Display: VFD
Programmable: Yes
