Tektronix TRCP0600 Current Probe, Rogowski, AC, 500 mA, 12 Hz to 30 MHz, 600 A, 100X, TRCP Series-Tektronix Company

Tektronix TRCP0600 Current Probe, Rogowski, AC, 500 mA, 12 Hz to 30 MHz, 600 A, 100X, TRCP Series

$2,810

Model :

TRCP0600

Tektronix TRCP0600 AC-Only Rogowski Current Probe

Features and Specifications

AC only
12 Hz to 30 MHz
500 mA to 600 A peak
100X Attenuation

The TRCP0600 is designed for use on small form factor components. This AC-only Rogowski probe has a thin, flexible coil that can easily be wrapped around test points such as the leg of a transistor.

What's in the Box

AC power adapter

Brand: Tektronix

Bandwidth: 30 MHz

Attenuation: 100X

Maximum Current: 600 A

Series: TRCP Series

Input Coupling: AC

Series Compatibility: 2 SERIES MSO MIXED SIGNAL OSCILLOSCOPE, 3 SERIES MDO MIXED DOMAIN OSCILLOSCOPE, DPO/DSA/MSO70000, DPO7000C, MDO3000, MDO4000C, MSO/DPO2000, MSO/DPO2000B, MSO/DPO3000, MSO/DPO4000, MSO/DPO5000, MSO/DPO5000B, MSO4000B, TBS1000/TBS1000B/TBS1000B-EDU, TBS2000

Minimum Current: 500 mA

Peak Current: 600 A
