Amprobe ACDC-100 TRMS AC/DC Clamp Meter

Features and Specifications

• True-rms
• Measures AC current to 800A and DC current to 1000A, AC/DC voltage to 600V, plus capacitance, and resistance
• The continuity beeper quickly identifies shorts and opens
• Relative zero mode displays the difference between the actual reading and a stored reference value and may be used with any function or range
• Data hold freezes the reading on the display for further analysis
• Diode test quickly finds voltage drops
• MAX capture function measures inrush current (30 mS response)
• Combines user friendly features such as a large, easy to read backlit digital display, auto power-off to conserve battery life, and a third hand test probe holder
• Rubber over-molded case absorbs shock and provides built-in probe storage
• Accommodates conductors up to 2.0 inch (50 mm) in diameter
• CAT III 600 V rated

The ACDC-100 TRMS 1000 A digital clamp meter offers superior accuracy, quality and reliability with all the basic measurement capabilities technicians need in an AC/DC current clamp meter. Use it to measure AC current to 800 A, DC current to 1000 A, and AC/DC voltage from 400.0 mV to 600 V.

Its large jaws accommodate conductors up to 2 inch (50 mm) in diameter for industrial applications. The features include large conductor size and in-rush current measurement along with AC / DC voltage, AC / DC current, resistance, continuity and diode tests. Its enhanced ergonomic design makes it a great choice for a clamp with professional digital multimeter (DMM) capabilities.

What's in the Box

• ACDC-100 TRMS clamp meter
• Deluxe carrying case
• Test leads
• Batteries (installed)
